Place of Origin : Zhejiang, China
Brand Name : CHENLONG
Certification : CE,ISO9001,ISO14001,OHSAS18000
Supply Ability : 100 Set/Sets per Month
Packaging Details : Packing
MOQ : 1 Set/Sets
Price : $10000 - $15000 / Set
Delivery Time : 35workdays
Power (kW) : 4
Weight (KG) : 2800
Key Selling Points : Energy saving
Warranty : 1 YEAR
After-sales Service Provided : Free spare parts, Online support, Free spare parts,online support
Applicable Industries : Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Construction works , Energy & Mining, Metal Processing Factory
POWER : UP TO CUSTOMER
Voltage : 380V/220V/415V/440V/3ph/50hz
Machine Designers : 10
Work Staffs : More than 200
Company Area : More than 65000 square meters
Clamping : Hydraulic
Saw Frame Feeding : Hydraulic
Controlling Mode : Full automatic or semi-automatic
Port : Ningbo,Shanghai
CHENLONG GZ-4250 Double Column Fully Automatic Band Saw
Zhejiang Chenlong Sawing Machine Co., Ltd. (Former Zhejiang Chenlong Sawing Machine Group) was founded in 1985. Nowadays, having 66000 square meter plant area and with total assets 150 million, CHENLONG is one of the biggest manufacturer in china and a vice president company of the council of china band saw industry Association. With strong technical force, excellent manufacturing equipment and advanced production technology, CHENLONG is first company to carry out the 6S management, ISO 9001 Quality System Certifying, ISO14001 environmental protection system certifying and OHSAS18001 Occupational Health and Safety Assessment Series certifying, and we are keep moving to improve. Zhejiang Chenlong sawing machine Co., Ltd. had been listed on NEEQ since August 2014.
Product parameters | |||
Model No. | GZ4250 | ||
Max.cutting | Round | 500mm | |
capacity | Quadrate | 500×500mm | |
Saw blade | Speed | 25/45/75m/min | |
Size | 41×1.25×5450mm | ||
Guides | Carbide and bearing blade guides | ||
Cleaning | Wire brush &flood coolant | ||
Tension | Manual | ||
Motor output | Blade | 4kw | |
Hydraulic | 0.75kw | ||
Coolant | 0.06kw | ||
Longest single feeding | 500mm |
| |
Work Vice | Hydraulic |
| |
Height of working table | 620mm | ||
Hydraulic tank volume | 60L | ||
Cooling box volume | 30l | ||
Machine weight | 2800KGS | ||
Machine size(L×W×H) | 2700×2300×1800mm |
![]() |
GZ-4250 60L Hydraulic Tank Volume Professional Band Saw Images |
